Frame and Forks
Frame: Raze 29 6061 Alloy Stealth Evo, Hydroformed tubing
Forks: RockShox 35 Gold 29 RL, 150mm, Solo Air, tapered steerer tube, Boost 15 x 110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
Rear Shock: Fox Float DPS LV EVOL Performance, 205 x 57.5mm. Settings: rebound, 3-position compression adjustment (Open/Mid/Lock), air preload. Trunnion top mount, 25 x 8mm bottom bushings
Headset: Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top
Drivetrain
Crankset: SRAM SX Eagle, Boost, DUB axle, Direct Mount chain ring, Small / Medium size: 170mm, Large / X-Large size: 175mm
Bottom Bracket: SRAM DUB BSA, sealed bearings, 73mm
Rear Derailleur: SRAM SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1 x 12 Speed, X-actuation 1:1
Cassette: SRAM PG-1210, 11-50 Tooth, 12 Speed
Chain: SRAM SX Eagle, 12 Speed, Powerlock
Braking/Shifting
Shifters: SRAM Trigger SX Eagle, 12 Speed, X-Actuation 1:1
Front Brake: SRAM Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear Brake: SRAM Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake Levers: SRAM G2 R, tool-free reach adjust, lever pivot bushings
Wheels
Rims: Mavic CrossMax XL S, 29" Boost 30mm internal width, hookless, tubeless ready, 24 spokes
Front Hub: Formula DC711, Boost 15x 110mm, sealed bearings, IS 6 bolts
Rear Hub: Formula DHT148 Boost 12 x 148mm, sealed bearings, IS 6 bolts
Front Tyres: Maxxis Dissector 29 x 2.4" WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
Rear Tyres: Maxxis Aggressor 29 x 2.3", tubeless ready, dual compound, Exo protection, 60TPI, folding bead
Finishing Kit
Handlebars: Onoff Sulfur 1.0 double-butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips: Onoff Twin, 1lock-on, 135mm
Stem: Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Seatpost: Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, Small size: 405 x 95-125mm, Medium size: 458 x 120-150mm, Large size: 498 x 140-170mm, X-Large size: 558 x 170-200mm
Saddle: Mondraker MDK Series, SRX, steel rail
