Frame:
Raze 29 Stealth Air full Carbon, Zero Suspension System, 130mm travel, Forward Geometry, Carbon Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, HHG internal cable routing, Enduro MAX sealed bearings, shock mudguard, ISCG 05, custom frame protectors.
Rear Shock:
Fox Float DPS LV EVOL Performance, 205x57.5mm. Settings: rebound, 3-position compression adjustment (Open/Mid/Lock), air preload. Trunnion top mount, 30x8mm bottom bushings
Fork:
Fox 36 29 Float GRIP EVOL Performance, 150mm, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
Number of Gears:
12
Gear Shifters:
Sram Trigger NX Eagle, 12s, X-Actuation 1:1
Chainset:
Truvativ Stylo 7k Eagle, Boost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm
Chainrings:
32T, CNC-machined alloy, X-SYNC 2
Rear Cassette:
Sram XG-1275, 10-52T, 12s
Chain:
Sram NX Eagle, 12s, Powerlock
Rear Derailleur:
Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Bottom Bracket:
Sram DUB BSA, sealed bearings, 73mm
Rims:
DT Swiss XM1700 Spline 29, 30mm internal width, welded aluminum, tubeless ready, 28 spokes
Front Hub:
DT 350, Boost 15x110mm, IS 6 bolts
Rear Hub:
DT 350, Boost 12x148mm, 36T SL Ratchet system, IS 6 bolts, XD freehub
Front Tyre:
Maxxis Dissector 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
Rear Tyre:
Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead
Brakes:
Sram G2, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
Handlebars:
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Handlebar Grips:
Onoff Diamond, 1lock-on, 135mm
Headset:
Acros custom for 1-1/2" head tube, angular contact bearings40x52x7, Internal cable routing
Stem:
Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Saddle:
Fizik Antares R7
Seatpost:
Onoff Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm
Weight:
13.2 kg
